Engineering Plastics - Extrusion Machinery

Twin Screw Extruder For Engineering Plastic Pelletizing

TSE Series Engineering plastic twin screw extruder line mainly used for making engineering plastics such PA, PA66, Glass Fiber, Carbon Fiber, Fire Resistance Agent, Foaming Agent etc. We has full experience in this application, each year we sold more than 30 lines for engineering plastics.

Engineering plastics are widely used application in our life, our engineering plastic compounding extruder line mainly used for making engineering plastics pellets such as fire resistance, fiber glass, carbon fiber etc.

Advantages of Our Color Masterbatch Twin Screw Extruder

– Good Dispersion and Compounding

– Easy Solution For Cleaning the Screw

– Uniform and Beautiful End Pellet

– Easy Operation and More Stable

– Main Technical Parameters

Main Technical Parameters

Model	Dia	RPM	L/D	Motor	Output Capacity
TSE-20	21 mm	600/800	32-60	5 kw	2-10 kg/h
TSE-36	35.6 mm	600/800	32-60	18.5/22 kw	10-100 kg/h
TSE-50	50.5 mm	600/800	32-60	55/75 kw	100-350 kg/h
TSE-65	62.4 mm	600/800	32-60	90/110 kw	350-500 kg/h
TSE-75	71 mm	600/800	32-60	132/160 kw	500-1000 kg/h
TSE-95	93 mm	600	32-60	250/315 kw	1000-2000 kg/h
TSE-135	135 mm	600	32-60	500/900 kw	3000-5000 kg/h
